Standard Precision GNSS Products

Standard Precision GNSS Products

To promote the use of GNSS in large-scale, mass-market applications, Unicore provides a range of low power consumption, miniaturized, standard precision modules for markets such as the Vehicle navigation,  time synchronization for cellular base stations, Cosumer drones, and for people and asset tracking. As a leading GNSS company, our products features in high performance, cost-effective, power efficient, and small size. Unicore's automotive grade GNSS modules have been widely applied by worldly well known automobile companies.

To promote the use of GNSS in large-scale, mass-market applications, Unicore provides a range of low power consumption, miniaturized, standard precision modules for markets such as the Vehicle navigation,  time synchronization for cellular base stations, Cosumer drones, and for people and asset tracking. As a leading GNSS company, our products features in high performance, cost-effective, power efficient, and small size. Unicore's automotive grade GNSS modules have been widely applied by worldly well known automobile companies.

Products

Types of Standard Precision GNSS Products

    UC6580

    Dual-frequency Multi-constellation GNSS Positioning SoC

    UM620A

    Automotive Grade Dual-frequency Multi-System GNSS Positioning Module

    UM620

    Industrial Grade Dual-frequency Multi-GNSS Positioning Module

    UM621A

    Automotive Grade Dual-frequency Multi-GNSS Integrated Positioning Module

    UM621

    Automotive Grade Dual-frequency Multi-GNSS Integrated Positioning Module

    UC6226

    Multi-GNSS Positioning SoC

    UM220-INS NL

    Industrial Grade Multi-GNSS Integrated Navigation and Positioning Module

    UM220-INS NF

    Automotive Grade Multi-GNSS Integrated Navigation and Positioning Module

    UM220-IV NV

    Automotive Grade Multi-GNSS Navigation and Positioning Module

    UM220-IV NL

    Industrial Grade Multi-GNSS Navigation and Positioning Module

    UM220-IV M0

    Industrial Grade Multi-GNSS Navigation and Positioning Module

    UM220-IV L

    Single-frequency Multi-GNSS Timing Module

    Standard Precision GNSS Products Features

    UFRIN technology uses original output of the already-existing inertial sensor to determine whether the vehicle's motion and navigation's filtered error converge without considering the installation angle. Once the GNSS has been lost, the algorithm estimates the car movement's restrictions and creates virtual observation to suppress the accumulation of IMU's error. This will help to ensure unrestricted installation and MEMS accuracy and keep the navigation stable, reliable and accurate. It includes data collection, vehicle's movement verification, carriage phase convergence verification, installation angle / installation angle error calibration and vehicle's integrated position. This kind of technology will help to reduce the dependency on the satellite information and improve navigation's reliability in the complex landscape of modern urban areas.


    Standard Precision GNSS Products Features
    Standard Precision GNSS Products FAQs
    FAQS

    Standard Precision GNSS Products FAQs

    • What is the inertial navigation deviation of UM220-IV INS module for half an hour?

      There will be 10 to 15 meters deviation for the inertial navigation with odometer input after running for 3 kilometers. The actual accuracy of inertial navigation may vary due to the difference in application environment and the deviation indicators.


      The deviation of pure inertial navigation of Unicore products is 5% of the driving distance (without odometer, about 5 meters deviation for 100 meters distance). With the odometer input, the accuracy will be improved and maintains precise for a longer time.


    • What is the difference between the positioning accuracy unit RMS and CEP?

      There are three units of the positioning accuracy: CEP, RMS, and 2DRMS. RMS is 1 sigma or 1 standard deviation; if the result is unbiased, the probability is 67%. 2DRMS is 2 sigma or 2 standard deviation, and the probability is 95%. The conversion rules between the three units are as follows:


      CEP × 1.2 = RMS


      CEP × 2.4 = 2DRMS
